Contactor, an accessory for bonding and connecting wires made of hardwood.

Connection “methodA”:
Turn the contactor to the side with two holes at an angle of 45 °.
Two wires are intertwined.


Connection “method B”:

Due to the excentric placement of two holes, the incoming wire wraps around the departing wire and the latter remains flat.

                                                             VIDEO:

Contactor

Copper coils

Seler: Za 5 d.o.o., Zg. Duplek 8 č, 2241 SP. Duplek, Slovenija

We produce high quality copper coils. We made a device that allows us to accurately produce the desired length, diameter and number of windings. Machine is calibrated for each coil for evenly winding (evenly distance between turns). This is important in the NANO coating. A few details of manufacture you can found HERE.


Technical information:

The dimension of the copper wire is Ø 1.64 mm = 2,5 mm2. The tag is H07V-U. It is generally used for electrical wiring.  Manufacturer of wire: Eurocable.

Number of windings: 144 turns for bigger coils and 81 turns for smaller coils. The inner diameter of the coil: Ø 10 mm for the thicker coils and Ø 6 mm for the thinner coils.

Note:

TAX (VAT) included. Duties and Taxes may be collected at delivery

(Non EU countries).


The maximum order is 30 sets of coils. For larger orders we make an individual offer.

Connecting the coils:

The number of plates you buy

1 - 3

4 - 10

11 - 20

21 - 50

51 - 100

>100

Zinc 50 x 98

3,00

2,50

2,00

1,50

1,20

1,00

Zinc 100 x 98

5,50

4,50

3,50

2,50

2,10

1,90

Zinc 200 x 98

10,00

8,00

6,00

5,00

4,10

3,70

Copper 50 x 100

1,90

1,70

1,50

1,30

1,10

1,00

Copper 100 x 100

3,70

3,30

2,90

2,50

2,10

1,90

Copper 200 x 100

7,30

6,50

5,70

4,90

4,10

3,70

Titan - zinc 100 x 80

3,70

3,30

2,90

2,50

2,10

1,90

Titan - zinc 200 x 80

7,30

6,50

5,70

4,90

4,10

3,70

Zinc and copper plates - the price list in EUR (€):

The prices depend on the quantity. For custom dimensions, we make an individual offer. Shipping costs depend on the weight of the ordered products. See the pricelist of shipping costs …

Connection with Method “A”

The two wires are twisted in a way to take place around one another. It appears that this is the most common way of connecting.

See image below.

Connection with Method “B”

The incoming wire is wrapped around the outgoing wire. By default, the direction of the winding is in the same direction as the windings of the coils. Alternatively, you can choose the direction yourself.

Back

Connection with Method “C” - for vertical coils

The incoming wire is wrapped around the outgoing wire. The direction of the winding is the same to the direction of the coils' windings. This is similar to method "B", except that the outgoing wire extends in the direction of flow of plasma (not returning in the same direction). According to Blueprint this is the correct method of connecting two wires. See images below.

Back

Instructions for use: Push two wires that you want to connect into the holes (so that the flow direction of the Plasmas is such as shown by the arrow on the Contactor - type “B”). Then rotate the Contactor.

You can make your own contactor as well – to obtain the guide for creating one, click HERE.


A few good sketches in 3D program has sent us Mr Marat from Russia:

Source: https://grabcad.com/3dmodeling24-1

Direct link: https://youtu.be/IHszj2kvo6Q

Coils maker - handy
